Tsev / Cov khoom / Lub tshuab nqus tsev rauv Parts

Lub tshuab nqus tsev rauv Parts



Siab -Cov Khoom Siv Ua Haujlwm Carbon rau Kev Pabcuam Lub Tshuab Nqus Tsev







Professional Graphite Felt, Carbon Carbon Composite Materials Chaw tsim tshuaj paus



Txij li thaum xyoo 2001, Dalian Shuangji Technology Development Co., Ltd. tau tsom mus rau kev tsim, ua thiab muag khoom ntawmcarbon- cov khoom siv carbon, nrog rau cov pa roj carbon zoo thiab lwm yam khoom siv thermal rwb thaiv tsev.

Tau ntau xyoo, peb tau sau cov kev paub nplua nuj thiab kev ua tiav hauv thaj chaw ntawm graphite muab ob qho tib si hauv tsev thiab thoob ntiaj teb. Nrog peb cov kws tshaj lij hauv graphite cov ntaub ntawv thiab cov ntawv thov, nrog rau peb cov khoom siv dav dav thiab cov kev pabcuam kev pabcuam uas npog cov graphite mos, tawv tawv, thiab cov pa roj carbon-carbon composites, peb tau tsim peb tus kheej los ua tus khub nyiam rau peb cov neeg siv khoom. Txawm tias thaum ntsib nrog cov ntawv thov nyuaj tshaj plaws, peb tuaj yeem ua haujlwm ze nrog cov neeg siv khoom los nrhiav cov kev daws teeb meem zoo tshaj plaws ua ke.

Peb cov graphite rigid muaj kev xav, muag muag, C / C cov ntaub ntawv sib xyaw, thiab cov khoom siv tshuab txhua yam muaj ntau yam kev siv. Piv txwv li, carbon-carbon composite khoom ua si lub luag hauj lwm tseem ceeb nyob rau hauv lub kub cheeb tsam ntawm monocrystalline silicon, thaum CFC racks, load- bearing daim hlau, channels & profiles, bolts, thiab txiv ntseej yog dav siv nyob rau hauv kev kho cua sov txheej txheem. Cov ntawv thov sib txawv no ua rau pom peb lub peev xwm tshaj lij thiab kev paub dhau los hauv kev ua cov khoom siv carbon.

01/

Kev pab txhawb nqa

Peb pab pawg txhawb nqa kev pabcuam yog nyob ntawm no los pab koj xaiv cov khoom lag luam zoo tshaj plaws rau koj daim ntawv thov thiab cov txheej txheem. Raws li ib tuggraphite chaw tsim tshuaj pausrau siab- cov khoom siv rwb thaiv tsev kub, C / C composites, peb ua haujlwm ze nrog peb cov neeg siv khoom, muab kev pabcuam xaiv, kev txhawb nqa tsim, thiab kev pabcuam tsim khoom rau carbon fiber ntau cov ntaub ntawv xws li carbon-carbon composites thiab carbon felts haum rau ntau yam siab -kub siv.Tau ntau xyoo, peb tau muab cov khoom muaj zog, sib zog, thiab ruaj khov carbon fiber ntau, graphite mos zoo li, kev xav tsis zoo, thiab lwm yam khoom, muab tus nqi -cov kev daws teeb meem zoo rau ntau yam kev siv thiab kev lag luam.

02/

Kev paub nplua nuj

Raws li ib tus neeg muag khoom tshwj xeeb hauv C / C cov ntaub ntawv sib xyaw thiab cov khoom siv carbon, peb muaj 23 xyoo ntawm kev tshawb fawb, sib piv, thiab tshuaj ntsuam graphite raw cov ntaub ntawv ob leeg hauv tsev thiab txawv teb chaws. Peb muaj kev nkag siab zoo txog lub cev lub cev, qhov zoo, thiab qhov tsis zoo ntawm cov khoom siv thoob ntiaj teb. Nrog peb tus kheej cov ntaub ntawv, peb tuaj yeem muab cov neeg siv khoom nrog cov khoom siv tau zoo dua, hloov pauv, thiab kev daws teeb meem kev ua tau zoo. Tsis tas li ntawd, peb ua tau zoo hauv kev ua kom ntseeg tau cov khoom lag luam siab, kev ua siab ntev ntev, thiab polishing sib xws hauv peb cov khoom ua tiav. Los ntawm kev siv scalable thiab raug nqi- siv tau C/C composites los hloov cov ntaub ntawv ib txwm, SHJ tuaj yeem pab koj ua tiav cov kev xav tau ua tau zoo yav dhau los thiab cov hom phiaj kev ruaj ntseg.

03/

Kev Pabcuam

Peb pab neeg ua haujlwm muaj cov kws tshaj lij kws tshaj lij engineers uas tau ua haujlwm hauv lub tshuab nqus tsev rau ntau tshaj 20 xyoo. Lawv ua tau zoo nyob rau hauv kev ua kom zoo ntawm lub tshuab nqus tsev kub qhov chaw cov qauv thiab lub tshuab nqus tsev, tshwj xeeb hauv lub tshuab nqus tsev tsim, kev hloov kho, kev saib xyuas, kev muag khoom, thiab tom qab- kev muag khoom. Peb tuaj yeem muab cov tuam txhab tsim khoom thiab cov neeg siv nrog cov lus pom zoo los yog kev paub ua kom haum rau cov khoom siv graphite sib txawv thiab kev ua haujlwm ib puag ncig, pom zoo kom haum cov ntaub ntawv carbon fiber ntau raws li kev ua haujlwm ntawm lawv lub qhov cub.



Tsis tas li ntawd, peb kuj muab cov lus qhia tsim nyog rau daim ntawv thov lossis ntawm -cov lus qhia kev teeb tsa ntawm qhov chaw los pab cov neeg siv khoom xaiv cov pa roj carbon zoo - cov pa roj carbon sib xyaw, cov pa roj carbon monoxide, thiab lwm yam khoom siv graphite.

04/

Kev xa khoom thoob ntiaj teb

Nrog rau kev nthuav dav ntawm peb lub lag luam, peb cov khoom tam sim no tau muag rau ntau tshaj 30 lub teb chaws thiab cheeb tsam thoob plaws Asia, Europe, Oceania, South Africa, thiab North America. Peb tuaj yeem hloov kho cov kev daws teeb meem rau cov pa roj carbon fiber ntau thiab cov pa roj carbon - cov ntaub ntawv sib xyaw ua ke raws li cov neeg siv khoom xav tau, muab ntau yam kev xaiv xws li cov thawv ntoo thiab pallets. Nyob ntawm qhov hnyav ntawm cov khoom thauj thiab kev xa khoom, peb xaiv tus nqi tshaj plaws - txoj kev thauj mus los tau zoo, suav nrog kev xa khoom xa tuaj, hiav txwv freight, huab cua freight, tsheb thauj mus los, thiab kev thauj mus los ntau yam.





05/High-Cov khoom zoo

Peb muab ntau yam khoom siv CFC, suav nrog cov cua sov, U / L profiles, fasteners, screws, phaj, kho cua sov rauv racks, thiab CFC machined qhov chaw. Vim lawv cov khoom tshwj xeeb, cov khoom no tau pom cov ntawv thov dav hauv ntau yam lag luam xws li kev lag luam tsheb, tshuaj, photovoltaics, thiab semiconductors. Piv txwv li, lawv tau siv los ua cov khoom siv kub hauv cov khoom siv photovoltaic crystalline silicon kev loj hlob, hauv cov khoom siv hluav taws xob semiconductor ingot furnaces, thiab ua cov pawm rau tsheb. Tsis tas li ntawd, peb cov khoom siv high -purity carbon fiber rwb thaiv tsev, graphite rigid felts, thiab soft felts kuj haum rau siab - kub daim ntawv thov nyob rau hauv inert los yog lub tshuab nqus tsev ib puag ncig.



Peb tos ntsoov yuav tham nrog koj los txiav txim seb qib twg ntawm graphite yog qhov zoo tshaj plaws rau koj daim ntawv thov.



CFC cov khoom:

CFC Fasteners, Springs, Rods, Fixtures, Grids, Baskets, Shelves, U/L/H Profiles, Channels, Crucibles, Pwm, Heaters, Phaj thiab lwm yam.

Graphite Felt - Cov khoom siv rwb thaiv tsev kub:

Graphite rigid xav, mos mos. (Peb tuaj yeem muab graphite xav tau los ntawm PAN-raws li, rayon-raws li, thiab suab- cov ntaub ntawv raws li.)





CFC (Carbon Fiber Composites): Lub teeb yuag thiab ruaj khov rau lub tshuab nqus tsev vacuum





Tsev 123 Rau sab kawg 1/3

Rigid Graphite Felt



◆ Cov ntsiab lus

Rigid Graphite Felt yog ua tib zoo tsim los ntawm cov txheej txheem tshwj xeeb, kev sib koom ua ke ntawm daim ntawv graphite, graphite xav, thiab cov ntaub ntawv carbon, tom qab ntawd los ntawm solidification, shaping, thiab thib ob siab -kub purification kev kho mob. Cov txheej txheem tsim tshwj xeeb no muab graphite xav tias nws cov yam ntxwv ntawm siab purity thiab siab carbon cov ntsiab lus, thaum tseem qhia tau zoo heev ablation kuj thiab thermal shock kuj. Tsis tas li ntawd, qhov kev xav pom tau zoo tshaj plaws hauv kev yaig airflow, thermal rwb thaiv tsev, thiab kev txuag hluav taws xob.

◆ Daim ntawv thov

Vim nws qhov kev ua tau zoo, cov graphite muaj kev xav tau pom dav dav hauv ntau qhov chaw, xws li ib qho siv lead ua kev loj hlob rauv, polycrystalline casting furnaces, polycrystalline txo rauv, polycrystalline ingot casting furnaces, lub tshuab nqus tsev sintering furnaces, kub xovxwm rauv, thermal tshuav nyiaj li cas rau nruab nrab cua sov, high- zaus induction furnaces, nrog rau siab - cov khoom siv kub hauv qhov tsis yog - oxidizing atmospheres thiab siab - purity silicon hydrogenation furnaces.

Nyob rau hauv lub tshuab nqus tsev cov khoom siv rauv, graphite nyuaj xav plays lub luag hauj lwm irreplaceable. Nws yog siv nyob rau hauv ultra-siab-kub lub tshuab nqus tsev siab-siab sintering rauv, muab kev txhawb zog rau cov khoom siv no. nws qhov kev ua tau zoo ruaj khov thiab txhim khu kev qha zoo ua rau cov khoom siv siab no - kawg ua haujlwm tsis tu ncua thiab ua tau zoo.

Nyob rau tib lub sijhawm, carbon thiab graphite rigid xav tau ua rau muaj txiaj ntsig zoo rau kev txhim kho cov kev lag luam muaj feem xyuam hauv kev lag luam hluav taws xob semiconductors, nqus hlau metallurgy, cov khoom siv tshuaj tshiab, thiab hnub ci photovoltaics.

◆ Kev Pabcuam Cov Neeg Siv Khoom

SHJ Graphite cov pa roj carbon zoo thiab graphite nruj zoo li rwb thaiv tsev machining muaj peev xwm ua rau peb muab cov khoom lag luam zoo, cov khoom siv thiab cov kev daws teeb meem. Peb cov engineers muaj lub peev xwm engineering los muab cov txheej txheem thermal tsim kom tiav rau koj daim ntawv thov.

Peb muab cov kev pabcuam customized raws li cov duab kos thiab muaj peev xwm tsim ntau yam uas tsis yog- qauv thiab cov duab geometric tsis zoo, xws li daim hlau tiaj tus thiab lub tog raj kheej.



rigid carbon fiber felt

Kev kho saum npoo

Kev kho saum npoo

Kev Tiv Thaiv Plua Plav

Airtightness

Kev tiv thaiv nto

Shock Resistance

Qhov zoo

Tsis Kho Nto

—

—

—

—

Zoo huab cua permeability thiab tus nqi qis

Graphite Ntawv Lamination

⌾

⌾

⭕

⭕

Los tiv thaiv- plua plav nkag thiab kub poob

Carbon Cloth Lamination

⭕

⭕

⌾

⭕

Kev tiv thaiv siab, Lub neej ua haujlwm ntev

Cov txheej txheem tshwj xeeb

⌾

⌾

⌾

⌾

Kev tiv thaiv - plua plav nkag, Kev Tiv Thaiv Kev Ua Haujlwm Siab, Siab Purity

Cov chav kawm tiv thaiv: — Chav Ⅰ ⭕ Chav Ⅱ ⌾ Chav Ⅱ
Specifications:

Khoom siv

Graphite Rigid Felt
(Pan-raws li)

Graphite Rigid Felt
(Pan-raws li)

Graphite Rigid Felt
(Rayon-raws li)

Kev ceev ceev

g/cm 3

0.17

0.2

0.15-0.17

Compressive zog

MPa

0.3

0.35

0.25

Thermal conductivity (@1000 degree)

W/(m.k)

0.35

0.43

0.20

Tshauv

ppm ua

Tsawg dua los yog sib npaug li 200

Tsawg dua los yog sib npaug li 200

Tsawg dua los yog sib npaug li 200

Ua haujlwm kub siab tshaj plaws

degree

3000

3000

2400

Kev kho saum npoo



Peb tuaj yeem muab ntau txoj hauv kev rau graphite rigid xav tau raws li qhov xav tau ntawm cov neeg siv, suav nrog kev siv cov txheej txheem tawv tawv, txuas cov ntawv graphite, pasting carbon daim ntaub, thiab txuas C / C daim hlau.

Qhov Loj tshaj plaws

mm

Loj: 2800 * 2100 * 300; Lub tog raj kheej: φ1800 / φ1400 * 1800

* Cov nqi saum toj no, qhov ntau thiab tsawg yog raug, tsis lav.

* Cov tsis muaj nyob rau hauv cov lus no yog cov khoom txheem. Yog tias xav tau cov khoom purity siab, kev kho kom huv tuaj yeem muab tau, nrog cov hmoov tshauv purified ntawm 20PPM siab tshaj plaws.

* Cov kev xav tau tshwj xeeb thiab siab - cov khoom lag luam kawg tuaj yeem raug kho los ntawm kev sib tham thiab kev sib txuas lus nrog peb lub tuam txhab.

Carbon thiab Graphite Soft Felts

Cov ntsiab lus

SHJ rwb thaiv tsev muag muag muaj qhov tsis tshua muaj thermal conductivity, muaj peev xwm tiv taus qhov kub thiab txias. Nws yog dav siv los ua cov khoom siv thermal rwb thaiv tsev rau ntau yam khoom siv siab - kub. Tsis tas li ntawd, vim nws qhov yooj yim, graphite mos muaj peev xwm ua rau cov chaw sib txawv, ua rau nws muaj kev xaiv rau cov khoom siv kho cua sov.

Ntxiv rau qhov siab purity, kub tsis kam, corrosion kuj, tsis yog - melting, thermal conductivity me me, siab kub tsis deformation thiab lwm yam zoo heev ntawm graphite felts, soft graphite felts kuj muaj qhov zoo ntawm lub teeb yuag thiab elasticity, yuav folded arbitrarily, txiav thiab sewn nrog graphite xov, thiab hais txog.

Peb tuaj yeem muab cov khoom lag luam customized raws li peb cov neeg siv khoom xav tau, muab cov ntaub ntawv sib txawv (PAN-raws li, Rayon-raws li) thiab kev ua tau zoo. Cov rwb thaiv tsev mos mos tuaj yeem tiv taus qhov kub txog li 3000 degree. Boasting a highly uniform thickness and density distribution, our soft felt ensures consistent and effective thermal insulation, delivering stable and long-lasting performance.

Daim ntawv thov

Graphite soft felt yog dav siv los ua cov khoom siv rwb thaiv tsev hauv ntau qhov kev lag luam, suav nrog kev lag luam hnub ci zog, semiconductor ib leeg -crystal silicon kev lag luam, kev lag luam siv lead ua hluavtaws, thiab kev lag luam fiber optics, nrog rau hauv siab - kawg lub tshuab nqus tsev sintering furnaces, cua sov kho qhov cub, thiab high{2} furnaces. Tsis tas li ntawd, graphite mos zoo li ua ib qho tseem ceeb ntawm insulating thiab refractory khoom nyob rau hauv ntau yam siab -kub furnaces xws li ib leeg-crystal furnaces, carburization furnaces, quartz furnaces, lub tshuab nqus tsev vacuum furnaces, induction furnaces, high-frequency furnaces, kev kho cua sov, furnaces, furnaces sintering furnaces, thiab siab - cua sov cua sov.

Kev Pabcuam Cov Neeg Siv Khoom

Graphite felts muaj nyob rau hauv ntau qhov ntau thiab tsawg thiab thicknesses kom tau raws li kev tsim qauv. Customized ntau thiab tsawg kuj muaj raws li qhov kev thov.

Nta

Ua ntej ntawm tag nrho cov, nws muaj ib tug siab purity, uas yuav ua tau zoo txo ​​los yog txo cov pa phem thib ob ntawm cov khoom, kom paub meej cov khoom zoo thiab purity.

Thib ob, graphite carbon xav tau qhia siab softness thiab lub teeb yuag cov yam ntxwv, ua rau nws muaj kev ua haujlwm zoo, tshwj xeeb tshaj yog tsim rau cov chaw ua haujlwm.

Thaum kawg, cov graphite carbon xav tau kuj muaj cov tuab tuab, uas ua rau nws yooj yim los tuav thaum ua, thiab qhov zoo yog ruaj khov thiab zoo ib yam, ntxiv kom ntseeg tau tias nws cov kev ua tau zoo hauv ntau yam kev siv.

Soft Graphite Felt



Specifications

Qib

TSF 1-01

TSF3-01

Khoom siv

Graphite Soft Felt
(Pan-raws li)

Graphite Soft Felt
(Rayon-raws li)

Kev ceev ceev

g/cm³

0.13

0.1

Thermal conductivity (@1000 degree)

W/(m.k)

0.24

0.15

Tshauv

ppm ua

Tsawg dua los yog sib npaug li 500

Tsawg dua los yog sib npaug li 200

Qhov siab tshaj plaws ua haujlwm kub

degree

3000

3000

Qhov Loj tshaj plaws

mm

Dav: 1600; Thickness: 5,10 hli

* Cov tsis muaj nyob rau hauv cov lus no yog cov khoom txheem. Yog tias siab - cov khoom purity xav tau, kev kho kom huv tuaj yeem muab tau, nrog cov hmoov tshauv purified tsawg dua lossis sib npaug li 20PPM siab tshaj plaws.

* Cov nqi saum toj no yog qhov raug, tsis lav.

* Peb muab kev kho kom haum rau cov kev xav tau tshwj xeeb thiab siab - cov khoom kawg los ntawm kev sib tham thiab kev sib txuas lus.

C/C Composite Materials

◆ Cov ntsiab lus

Cov pa roj carbon -carbon composites (C/C) yog lub teeb yuag thiab siab - cov ntaub ntawv muaj zog siab heev nrog lub peev xwm ua haujlwm ruaj khov nyob rau hauv siab - qhov kub thiab txias tshaj 3,000℃. Lawv tuaj yeem siv rau ntau yam kev siv, suav nrog rwb thaiv tsev, thermal rwb thaiv tsev, thiab thermal rwb thaiv tsev.

Cov pa roj carbon- cov ntaub ntawv sib xyaw xws li CFC daim hlau thiab cov channel yog cov pa roj carbon- cov ntaub ntawv rwb thaiv tsev uas tsim los ntawm kev siv cov pa roj carbon-raws li fibers lossis siab molding, ua raws li carbonization los yog siab - kub graphitization. Lawv tsis tsuas yog muaj lub cev zoo heev ntawm graphite lossis carbon cov khoom, tab sis kuj muaj lub teeb ci thiab yooj yim ntawm kev ua.

◆ Daim ntawv thov

CFC yog dav siv nyob rau hauv ntau yam xws li aerospace metallurgy, kev kho cua sov, semiconductors, photovoltaics, shipbuilding, thiab tsheb.

◆ Kev Pabcuam Cov Neeg Siv Khoom

Peb tau cog lus los muab peb cov neeg siv khoom raws li cov pa roj carbon monoxide- cov khoom siv carbon sib xyaw hauv ntau yam khoom xws li, tab sis tsis txwv rau, daim hlau, lub kaum ntse ntse, U- channels, rings, kav, raj, kab, bolts, ntxhua khaub ncaws, cua sov, racks, thiab thauj khoom - cov kabmob. Peb tau cog lus los ua kom tau raws li cov kev xav tau tshwj xeeb ntawm peb cov neeg siv khoom, kom ntseeg tau tias cov khoom sib xyaw carbon uas peb muab tau muaj peev xwm ua tau raws li qhov xav tau ntawm ntau qhov chaw ua haujlwm nyuaj thiab xav tau.

Nta

Carbon-carbon composites (C/C composites) yog carbon-carbon reinforced cov ntaub ntawv ntxiv dag zog los ntawm siab -cov pa roj carbon fiber ntau, qhia txog ntau yam ntawm cov yam ntxwv zoo kawg li.





Hwm Carbon Felt rwb thaiv tsev rau lub tshuab nqus tsev rauv Thermal Management







vim li cas xaiv peb



'Nws yog qhov txaus los ua haujlwm nrog Creative. amazingy koom, yooj yim rau kev sib txuas lus nrog. teb nrog iterations tom ntej, thiab ua haujlwm zoo nkauj.



High mechanical zog, siab elasticity, thiab siab toughness

C / C composites sawv tawm nrog lawv cov neeg kho tshuab siab zog, siab elasticity, thiab siab toughness. Piv rau isostatically nias graphite, cov khoom siv no tsis tsuas yog ua kom pom lub zog zoo dua thiab elasticity, tab sis kuj tseem muaj cov kab nrib pleb zoo heev thiab tsis muaj zog, ua kom nws ruaj khov thiab kav ntev hauv qhov chaw nyuaj thiab huab cua.




High tshav kub kuj

Kev kub siab ua haujlwm ntawm carbon-carbon composites yog lwm qhov tseem ceeb. Piv nrog rau cov khoom siv hlau, lawv tuav lub zog siab txawm tias qhov kub siab thiab tuaj yeem ua haujlwm ruaj khov hauv qhov kub siab tshaj 2000℃hauv cov pa roj inert, ua rau lawv tsis sib xws hauv siab -kub siv.




Lub teeb yuag thiab yooj yim kov

Ntxiv mus, lub teeb yuag ntawm carbon-carbon composites muaj nuj nqis heev. Nrog rau qhov qis dua piv rau cov khoom siv hlau, lawv tuaj yeem ua tau yooj yim tsim qauv, muab cov kev daws teeb meem yooj yim dua thiab siv tau rau ntau yam kev siv.




Achievable siab thermal conductivity

Nws yog ib qho tsim nyog hais tias dhau los ntawm kev siv cov cuab yeej siv hluav taws xob zoo tshaj plaws, cov pa roj carbon -carbon composites tau ua tiav cov thermal conductivity coefficient siab dua tooj liab. Cov yam ntxwv no ua rau lawv muaj kev thov dav dav hauv thaj chaw uas yuav tsum tau ua kom muaj cua sov zoo, xws li aerospace thiab khoom siv hluav taws xob.



Hauv cov ntsiab lus, C / C cov ntaub ntawv sib xyaw nrog lawv cov tshuab ua haujlwm siab, siab elasticity, siab toughness, siab kub tsis kam, lub teeb yuag, thiab siab thermal conductivity, tau dhau los ua cov khoom siv tseem ceeb hauv kev lag luam niaj hnub no.



Product Description
productcate-800-533

CFC phaj

Lub CFC phaj yog tsim los ntawm siab -siab molding ntawm cov ntaub ntawv carbon, featuring ib tug impressive 80% ntev- fiber ntau cov ntsiab lus. Qhov no ua rau cov yam ntxwv tshwj xeeb xws li lub zog siab, oxidation tsis kam, cov khoom siv tsis sib xws, thiab cov qauv ruaj khov.

Vim yog cov khoom no, CFC phaj pom ntau daim ntawv thov hauv ntau qhov kev lag luam, suav nrog photovoltaics, semiconductors, lub tshuab nqus tsev kho cua sov, siab - kub brazing furnaces, thiab siab -kub sintering furnaces.

CFC Fastener

Carbon Carbon Composite Fasteners yog tsim los rau kev sib txuas fastening xav tau nyob rau hauv ntau qhov chaw ntawm qhov kub thiab txias, muaj ntau yam zoo heev. Nws lub zog siab, tsis tshua muaj thermal conductivity, lub teeb yuag, tsis tshua muaj coefficient ntawm thermal expansion, uas qhia tau zoo heev cuam tshuam thiab thermal shock kuj. Nyob rau tib lub sijhawm, lub fastener muaj kev nyab xeeb thiab txhim khu kev qha, tsis plam lossis tawg thaum siv, thiab cov qauv ruaj khov thiab txhim khu kev qha. Kev ua tau zoo heev hauv tensile zog, siab modulus.

Lub fastener yog dav siv nyob rau hauv photovoltaic, semiconductor, siab kub lub tshuab nqus tsev thiab cua rauv xws li lub tshuab nqus tsev kho cua sov rauv, siab kub brazing rauv, kub kub sintering rauv thiab lwm yam teb, muab ib tug txhim khu kev qha kev daws rau qhov kev twb kev txuas fastening nyob rau hauv kub kub ib puag ncig.

Cov ntawv thov muaj xws li: cov khoom cua kub, lub tshuab hluav taws xob, cov khib nyiab, cov khoom siv hluav taws xob, cov khoom siv hlau molten, cov hmoov metallurgy thiab hlau txhaj tshuaj molding sintering tais thiab cov nkoj, siab temp fasteners, iav manufacturing, tshwj xeeb sib tw brakes thiab clutches, spark plasma sintering, thiab teb pab sintering tshuab.

productcate-800-533
productcate-750-750

Cheebtsam ntawm Load Bearing Structure

Cov pa roj carbon - cov khoom siv hluav taws xob xws li CFC txiv ntseej, lub caij nplooj ntoos hlav thiab ntsia liaj qhov rooj sawv tawm rau lawv qhov kev ruaj ntseg zoo heev, thermal conductivity thiab durability, nrog rau lawv cov khoom muaj zog tensile thiab siab modulus.

Cov khoom zoo no tau ua rau ntau yam kev siv hauv photovoltaics, semiconductors, lub tshuab nqus tsev kho cua sov, siab -kub brazing furnaces, siab -kub sintering rauv, thiab ntau lwm yam. Txawm hais tias nws nyob hauv ib puag ncig uas yuav tsum tau muaj kev tswj xyuas qhov tseeb, lossis qhov twg ua tau zoo thermal conductivity thiab ntev - kav ntev yog qhov tseem ceeb, carbon- cov qauv carbon yog tshwj xeeb nyob rau hauv muab cov kev daws teeb meem txhim khu kev qha rau ntau hom kev siv kub -.

CFC U/L/H Profile thiab CFC Saggar

CFC U / L / H profiles muaj lub zog siab, siab carbon fiber ntau, lub neej ntev, thiab siab purity.

Cov pa roj carbon / carbon saggar yog siab -kub ntim khoom tsim los ntawm kev ua tiav ntawm cov khoom siv carbon / carbon sib xyaw. Nws boasts lub teeb yuag tsim, siab zog, zoo heev thermal shock kuj, siab purity, thiab zoo heev hnav tsis kam, ua rau nws ib tug superior upgrade rau tsoos graphite crucibles.

Cov pa roj carbon-carbon profile / channel qhia tau zoo heev thaum tshav kub kub, oxidation tsis kam, thermal shock resistance, thiab tshuaj corrosion kuj. Cov khoom no nthuav tawm lub zog tensile siab thiab modulus, tshaj graphite nyob rau hauv cov nqe lus ntawm lub zog thiab tawg tsis kam.

Vim yog cov khoom tshwj xeeb no, cov khoom siv carbon no - cov khoom siv carbon sib xyaw pom muaj ntau daim ntawv thov hauv ntau qhov chaw, suav nrog photovoltaics, semiconductors, lub tshuab nqus tsev kho cua sov, siab - kub brazing furnaces, thiab siab - kub sintering furnaces.

CFC Profile
productcate-800-408

CFC Lub tog raj kheej thiab cov cua sov

These CFC cylinder and heaters feature low density, high strength, minimal thermal deformation, uniform heat distribution, easy installation, and long lifespan.

CFC rhaub tuaj yeem siv rau hauv qhov system ntawm qhov kub thiab txias.

Cov chaw siv muaj xws li photovoltaics, semiconductors, lub tshuab nqus tsev kho cua sov rauv, siab -kub brazing furnaces, thiab siab -kub sintering rauv.

Specifications

Khoom siv



C/C

C/C

C/C

C/C

Kev ceev ceev

g/cm³

1.3

1.4

1.45

1.6

Compressive zog

MPa

Ntau dua los yog sib npaug rau 100

Ntau tshaj los yog sib npaug rau 150

Ntau tshaj los yog sib npaug rau 150

Ntau tshaj los yog sib npaug rau 150

Flexural zog

MPa

Ntau dua los yog sib npaug rau 120

Ntau dua los yog sib npaug rau 120

Ntau tshaj los yog sib npaug rau 150

Ntau tshaj los yog sib npaug rau 150

Tensile zog

MPa

Ntau tshaj los yog sib npaug rau 60

Ntau dua lossis sib npaug li 80

Ntau dua lossis sib npaug li 80

Ntau dua los yog sib npaug rau 100

CTE

10-6/ degree

Tsawg dua los yog sib npaug li 4

Tsawg dua los yog sib npaug li 4

Tsawg dua los yog sib npaug li 4

Tsawg dua los yog sib npaug li 4

Thermal conductivity (@1000 degree)

W/(m.k)

20-30

20-30

20-30

20-30

Tshauv

ppm ua

<200

<200

<200

<200

Qhov Loj tshaj plaws

mm

φ1800*φ1400*1800

* Cov tsis muaj nyob rau hauv cov lus no yog rau cov khoom txheem. Yog tias xav tau cov khoom purity siab, kev kho kom huv tuaj yeem muab tau, nrog cov hmoov tshauv purified tsawg dua lossis sib npaug rau 20PPM siab tshaj plaws.

* Cov nqi saum toj no yog qhov raug, tsis lav.

* Cov kev xav tau tshwj xeeb thiab siab - cov khoom lag luam kawg tuaj yeem raug kho los ntawm kev sib tham thiab kev sib txuas lus nrog peb lub tuam txhab.

FAQ

Q: Cov pa roj carbon -carbon composites yog dab tsi?

A: Carbon-carbon composites yog cov khoom siv qib siab uas muaj cov pa roj carbon fiber ntau ntxiv hauv cov pa roj carbon matrix.

Q: Cov khoom siv hluav taws xob zoo li cas yog cov pa roj carbon- cov pa roj carbon monoxide feem ntau siv hauv?

A: Cov pa roj carbon - carbon composites feem ntau yog siv nyob rau hauv ntau yam kev lag luam furnaces, xws li lub tshuab nqus tsev vacuum furnaces, lub tshuab nqus tsev brazing furnaces, thiab tshav kub kho rauv.

Q: Qhov zoo ntawm carbon-carbon fasteners yog dab tsi?

A: Cov pa roj carbon- cov pa roj carbon sib xyaw ua ke khav theeb ntau qhov zoo, suav nrog lub zog siab, tiv taus qhov kub thiab txias, thermal shock, thermal expansion coefficients, thiab corrosion kuj.

Q: Puas muaj cov pa roj carbon- cov pa roj carbon sib xyaw nrog cov duab tshwj xeeb tuaj yeem kho tau?

A: Yog lawm, peb tuaj yeem muab cov kev pabcuam customized raws li koj qhov kev siv tshwj xeeb. Yog xav paub ntxiv, thov hu rau peb.

Q: Cov kev lag luam twg yog cov pa roj carbon- carbon composites siv hauv?

A: Automotive Industry, Shipbuilding, Electronics, Chemical Industry, Photovoltaics thiab Semiconductors.
Daim Ntawv Thov Ntxiv: Dhau ntawm cov haujlwm no, carbon-carbon composites tau siv dav hauv cov haujlwm xws li lub zog, kev kho mob, thiab cov khoom siv kis las.
Ntim Cov Lus Qhia

Txhua yam khoom yog ntim ruaj ntseg hauv cov rooj plaub plywood.

Cov khoom ntawm tus kheej raug cais los ntawm cov npuas tuab kom tiv thaiv kev sib cuag thiab puas.

Cov ntsiab lus tau ntim nruj kom ntseeg tau tias muaj kev txav me me thaum caij tsheb thauj mus los.

Kev xaiv ntim khoom muaj nyob rau ntawm kev thov.
